Core Content: Zirconium Grinding Beads , Ceramic Grinding Media , High-Density Grinding Beads
Yiho Zirconium Silicate (ZS)Grinding Bead Type
Yiho ZS-410 Ceramic Beads are specially designed for superfine grinding mills with high speed and energy input.
Yiho ZS-420 Ceramic Beads are ideal combination of high grinding efficiency and low wear rate. It can be widely used in energy intensive mills.
Bead mill Zirconium ball Unique Product Features
Minimal fractured fragments due to the homogenous microstructure.
Superior milling efficiency due to high density and high degree of hardness.
Longer Life due to the high wear resistance & high crush load.
Enhanced mill life due to the high sphericity and homogenous surfaces.
Bead mill Zirconium ball Application
1. Metallic minerals like Copper, Silver, Nickel, Gold, Zinc, PGM, Lead, etc.
2. Non-metallic minerals like Graphite, Calcium Carbonate, Kaolin Clay, Zirconium Silicate, Titanium Dioxide, Gypsum and Quartz, etc.
3. Advanced Ceramic Materials, Frits and Glazes.
4. Chemical Material, Paint, Pigment, Printing Ink, Dye.
Bead mill Zirconium ball Technical Data
| Density | g/cm3 | > 4.1 |
| Packing density | g/cm3 | > 2.4 |
| Vickers Hardness | Kgf/mm2 | 1,000 – 1,050 |
| Roundness | % | > 95 |
| Standard size* | mm | 0.5-13 |
| Chemical compositio | Al2O3, ZrO2, SiO2 and others |
* Other sizes are available upon request
Bead mill Zirconium ball Packing
* Standard Packing
Net 1,000 KG in 1 Jumbo bag on Plastic pallet
Net 2,000KG in 1 Jumbo bag on Plastic pallet
* Customized Packing
Net 1,000KG in 1 jumbo bag in Wooden Crate
Other High Density Ceramic Grinding Media Balls can be produced
– Yttria zirconia Grinding Bead with more than 6.0 SG
-Ceria Zirconia Grinding Bead with more than 5.98 SG
