High Durability Customized Ceramic Wear Tiles for Increased wear resistance

Core Content: High Durability Customized Ceramic Wear Tiles、Severe Wear Lining Applications、Extreme Abrasion Resistant Ceramics

YIHO offers a full range of shapes and sized ceramic tiles for your severe wear lining applications. YIHO can offer standard sized tiles (square and rectangular), hex tiles as well as custom shapes and sizes for your demanding application.

YIHO  offers a complete material portfolio for these ceramic wear tiles including; several grades of Aluminum Oxide 92%, 95%, 99%, Zirconia Toughened Alumina(ZTA), Zirconia, Reaction Bonded Silicon Carbide as well as Sintered Silicon Carbide for your most extreme corrosion, abrasive and wear environments.

Pre-engineered alumina tiles are tailor made to suit any type of application such as short and long radius bends, small and large bore pipe sections, square to round transitions, cones, pipe junctions and connections etc. The ceramic wear tiles, when installed correctly, provide some resistance to low levels of shock and extreme sliding abrasion, caused by material passing over and wearing the surface of the part.

Ceramic Wear Tiles Application Area

– Classifiers and cones

– Fan impellers and casings

– Cyclone separator shells/Parts

– Hoppers and Chutes

– Tubes, pipes, Bends and Elbows

Ceramic Wear Tiles Specifications

Category	HC92	HC95	HCT95	HC99	HC-ZTA	ZrO2
Al2O3	≥92%	≥95%	≥ 95%	≥ 99%	≥75%	/
ZrO2	/	/	/	/	≥21%	≥95%
Density (g/ cm3  ）	＞3.60	＞3.65g	＞3.70	＞3.83	＞4.10	＞5.90
HV 20	≥950	≥1000	≥1100	≥1200	≥1350	≥1100
Rock Hardness HRA	≥82	≥85	≥88	≥90	≥90	≥88
Bending Strength MPa	≥220	≥250	≥300	≥330	≥400	≥800
Compression strength MPa	≥1050	≥1300	≥1600	≥1800	≥2000	/
Fracture Toughness (KIc MPam 1/2)	≥3.7	≥3.8	≥4.0	≥4.2	≥4.5	≥7.0
Wear Volume (cm3)	≤0.25	≤0.20	≤0.15	≤0.10	≤0.05	≤0.02

Ceramic Wear Tiles Specifications

Image	One Part of Related Main Size(mm)
	100*100*10/12/20/25/30/50	150*100*10/12/14/15/20/23.5/24/25/30/40/50/70
	150*50*12/10/20/25	100*100*10/12/20/25/30/50	120*80*10/12/20
	120*80*15	45*45*11	50*50*17
	70*70*20	75*75*50	80*40*30
	105*55*25	90*90*60	145*145*20
	200*200*60
	……
	Thickness can be adjusted and Size can be customised.
	Ceramic Trapezoidal Tile

Image	One Part of Related Main Size(mm)
	150*30/27*12.7	150*45/42*20	150*35/32*20
	150*20/17*10	150*30/27*10	150*35/33*10
	150*50/47*12	150*50/48*12	150*60/58*12
	100*38/20*25	100*66/30*25	100*50/49*18
	100*38/20*25	120*88/77*15
	……
	Thickness can be adjusted and Size can be customised.
	Ceramic Plain Tile

Image	One Part of Related Main Size(mm)
	150*100*15	100*10*18	150*100*10
	150*100*20	40*40*20	45*45*11
	45*45*20	45*45*30	45*45*50
	47.5*47.5*25	50*50*10	50*50*30
	75*50*20	100*25*6	100*25*10
	100*25*20	100*50*6	100*50*10
	100*100*10	120*40*6	150*150*6….
	Thickness can be adjusted and Size can be customised.
	Ceramic Brick

Image	One Part of Related Main Size(mm)
	H40	150*50/47*40	150*50*40
	H50	150*50/47*50	150*50*50
	H60	150*50/47*60	150*50*60
	H70	150*50/47*70	150*50*70
	H80	150*50/47*80	150*50*80
	H90	150*50/47*90	150*50*90
	H100	150*50/47*100	150*50*100
	Thickness can be adjusted and Size can be customised.

Image	One Part of Related Main Size(mm)
	100*100*10/12/20/25/30/50	150*100*10/12/14/15/20/23.5/24/25/30/40/50/70
	150*50*12/10/20/25	100*100*10/12/20/25/30/50	120*80*10/12/20
	120*80*15	45*45*11	50*50*17
	70*70*20	75*75*50	80*40*30
	105*55*25	90*90*60	145*145*20
	200*200*60
	……
	Thickness can be adjusted and Size can be customised.
	Ceramic Trapezoidal Tile

Image	One Part of Related Main Size(mm)
	150*30/27*12.7	150*45/42*20	150*35/32*20
	150*20/17*10	150*30/27*10	150*35/33*10
	150*50/47*12	150*50/48*12	150*60/58*12
	100*38/20*25	100*66/30*25	100*50/49*18
	100*38/20*25	120*88/77*15
	……
	Thickness can be adjusted and Size can be customised.
	Ceramic Plain Tile

Image	One Part of Related Main Size(mm)
	150*100*15
	150*100*20
	45*45*20
	47.5*47.5*25
	75*50*20
	Thickness can be adjusted and Size can be customised.
	Ceramic Plain Tile

Please contact us and allow our application engineers the opportunity to work with your engineering team to recommend the right advanced ceramic materials for your toughest challenges.
